用途及特點：
該漆由環氧酯漆與乙炔黑及礦物顏料經研磨而成，使用時加入適量的室溫干燥劑，耐熱等級為B級，漆膜堅硬、牢固、粘結力強，適于作高壓電機和大電機線棒、端部防電暈涂層。
技術條件：
外觀：干后膜應光滑，無雜質 干燥時間(23℃±2℃)：≤8h
固體含量(120℃±2℃至恒重)：≥55% 表面電阻系數：104-106Ω
防電暈漆性能特點和用途
Characteristics and Application of corona-proof varnish
特點和用途:耐熱等級B級。干燥性好。用于高壓電機線圈槽部表面防電暈覆蓋層。
標準: Q/XB1014-2011
Characteritics and Application: Temperature cassification is B. Good drying property. Used for corona proof coating of the slot of coils for high voltage motors.
Standard: Q/XB1014- -2011
131高電阻環氧防電暈漆 Epoxy varnish with high resistance and corona proof
特點和用途:耐熱等級B級。干燥性好。用于高壓電機線圈端部表面防電暈覆蓋層。
標準: Q/XB1015- -2011
Characteristics and Application: Temperature classification is B. Good drying property .Used for corona-proof coating of the end of coils for high voltage motors.
Standard: Q/XB1015- -2011
140改性聚酯低阻防電暈漆Modified polyester varnish, low- resistance and corona -proof
特點和用途:耐熱等級F級。附著力強，耐磨性好?？芍苯釉诰€棒表面使用。適用于60KV和10.5KV級高壓電機線圈或線棒槽部的防暈。
標準: Q/XB1091-2011
Characteristics and Application: Temperature classification is F. High adhesion and good wear -resistance. Used for the surface of bars directly as well as for
corona-proof treatment of motors' coils and slot of bars which voltage are 6kv and 10.5kv.
Standard: Q/XB1091-2011
141改性聚酯高阻防電暈漆Modified polyester varnish with high resistance and corona proof
特點和用途:耐熱等級F級。附著力強，耐磨性好?？芍苯釉诰€棒表面使用。適用于60KV和10.5KV級高壓電機線圈或線棒端部的防暈。
標準: Q/XB1091-2011
Characteristics and Application: Temperature lasificationis F. High adhesion and good wear resistance. Used for the surface of bars directly as well as for
corona-proof treatment of the end of motors' coils and end of bars which voltage are 6kv and 10.5kv.
Standard: Q/XB1091-2011
